N-Male flange Aircell-5

FEATURES, FUNCTIONS AND SPECIFICATIONS:
• Connector N-Male
• Type: Inner, Solder
• Type: Outer, Screw
• Use for: Aircell-5
• Packing: Bag-1

Mechanical specifications:
• Cables: Aircell 5
• Inner conductor: to solder
• Outer conductor: to screw
• Coupling tourque: 4 - 6 Nm

Electrical specifications:
• Impedance: 50Ω
• Return loss:
...≤-37.7dB@1GHz;
...≤ -30.0dB@3GHz;
...≤ -29.9dB@11GHz
• Insertion loss: ≤ 0.05 dB
